Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine

Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine

  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
  • Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine
Product Details:
Place of Origin: china
Model Number: QCF-10
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: US$7653.54/ pcs---US$9921.26/pcs
Packaging Details: 3700*920*1800MM, 1000KG
Delivery Time: 40-60day
Payment Terms: T/T, L/C
Supply Ability: 10
Contact Now
Detailed Product Description
Production Capacity: About 8,400 Pcs/hour Spoon Specifications: As Per Sample
Sealing Material: Film Power Supply: 380V50HZ
Motor Power: 1.0kw Heating Power: 4.8KW
Use Air Pressure: 0.5-0.75Mpa Maximum Air Consumption: 0.45m³/m
Machine Size: About 3700*920*1800MM Machine Weight: 1000KG
High Light:

Spoon Type Honey Packaging Machine

,

10 head Honey Packaging Machine

,

12 Head Automatic Honey Filling Machine

Spoon Type Honey Packaging Machine 10-12 head Bee Appliances Supplier Automatic Customised Honey Filling Machine



Technical process
Manually put the spoon→piston filling→UV lamp sterilization→automatically put film→film detection→sealing→suction cup



Cup part artificial
Sealing part made of copper
Double sealing to ensure tightness
The sealing temperature can be adjusted from 0 to 400 degrees
Independently controllable sealing temperature
Cup out system suction cup to suck out





Machine characteristics

Whole machine composition: Channel steel frame. Outsourcing 304 stainless steel
Template: Acid and corrosion resistant stainless aluminum





Configuration sheet



Serial Number Name Brand Model Place of Origin Specification
transmission
1 Main motor   Mitsubishi Japan
2 driver   Mitsubishi Japan
3 Reducer   ATG Shanghai
4 Mould       Stainless aluminum acid resistant
5 Mould chain
304 stainless steel

6 Main bearing   NSK Japan
7 Linear Bearings   EASE Japan
8 seal       95 pure copper block
Pneumatic Components
1 Cylinder   AirTAC Taiwan
2
Pressure regulating valve
  AirTAC Taiwan
3 Control valve   AirTAC Taiwan
4
2 points 3 position solenoid valve
  AirTAC Taiwan
5
3 points 3 position solenoid valve
  AirTAC Taiwan
6 Gas tank
304 stainless steel

Electrical components
1 PLC   Omron Japan
2 touch screen   Omron Japan
3
Emergency stop switch
  Schneider France
4 Work switch   Schneider France
5 Contactor   Schneider France
6 MCB   Schneider France
7 MCB   Schneider France
8 MCB   Schneider France
9
Two position switch
  Schneider France
10 Miniature relay   Omron Japan
11
Proximity switch
  AirTAC Taiwan
12
Temperature control
  Sinny China
13 Indicator light   Schneider France



Spoon Type Honey Packaging Machine 10-12 Head Automatic Honey Filling Machine 0
